UA8164-BE Coupled Inductor

General specification Core Material: Ferrite Weight: 430 mg Packaging: 250/7 reel, 1000/13 reel Plastic tape: 16 mm wide, 0.4 mm thick, 12 mm pocket spacing, 4.9 mm pocket depth Winding to Winding Isolation: 200 Vrms applied for 2 seconds Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info
