SER2012-901

General specification Core Material: Ferrite Weight: SER2009 = 6.65 – 6.89 g, SER2010 = 7.46 – 7.90 g, SER2011 = 8.63 – 9.08 g, SER2012 = 9.92 – 10.3 g, SER2013 = 10.8 – 11.4 g, SER2014 = 11.7 – 12.4 g Packaging: SER2009: 200 per 13 reel, Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 9.25 pocket depth SER2010: 200 per 13 reel, Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 10.5 pocket depth SER2011: 170 per 13 reel, Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 11.6 pocket depth SER2012: 150 per 13 reel, Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 13.0 pocket depth SER2013: 150 per 13 reel, Plastic tape: 44 mm wide, 0.5 mm thick, 32 mm pocket spacing, 14.0 pocket depth SER2014: 125 per 13 reel, Plastic tape: 44 mm wide, 0.5 mm thick, 32 mm pocket spacing, 15.0 pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
