RFS1412-393

General specification Core Material: Ferrite Weight: 6.0 – 7.0 g Packaging: 169 parts per tray Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at PCB Washing: Tested with pure water or alcohol only More info.

225,00 ₽

Артикул: RFS1412-393KE Категорий: High current radial lead, Power, Products, RFS1412-393, Shielded Inductors, РФС, РФС1412

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Inductance (H) 2 (Tolerance: &plusmn,10%)	DCR (Ω) 3		SRF typ (MHz) 4	Isat (A) 5			Irms (A) 6
Part number 1	Inductance (H) 2 (Tolerance: &plusmn,10%)	typ	max	SRF typ (MHz) 4	10% drop	20% drop	30% drop	20C rise	40C rise
RFS1412-393KE	39	0.060	0.066	7.7	3.1	3.9	4.3	2.9	3.9
