RA6998-BL

General specification Core Material: Ferrite Weight: 10.6 g Packaging: 200/13 reel Plastic tape: 44 mm wide, 0.37 mm thick, 32 mm pocket spacing, 9.35 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. More info.

1800,00 ₽

Артикул: RA6998-BLB Категорий: Planar Transformers, Products, RA6998, RA6998-BL, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 2 (Hover for schematics)	Inductance at 0A (H) 3 (Tolerance: &plusmn,20%)	DCR max (mΩ) 4			Leakage Inductance max (H) 5	Turns Ratio	Isolation Voltage (Vrms) 6
Part number 2 (Hover for schematics)	Inductance at 0A (H) 3 (Tolerance: &plusmn,20%)	Pri	Sec	Gate	Leakage Inductance max (H) 5	Pri : Sec : Gate	Isolation Voltage (Vrms) 6
RA6998-BL_	80	15.0	22.0	45.0	0.35	1 : 1.125 : 0.375	1500
