Q4337-BL

General specification Core Material: Ferrite Weight: 11.4 g Packaging: 100 parts per tray Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. More info.

1125,00 ₽

Категорий: Power Converter Transformers, Power Transformers, Products, Q4337, Q4337-BL, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Inductance at 0A (H) (Tolerance: &plusmn,15%)	Inductance min at 5 A (H)	DCR max (Ω) 1			Leakage Inductance max (H) 2	Turns Ratio	Isolation Voltage (Vrms) 3
Part number (Hover for schematics)	Inductance at 0A (H) (Tolerance: &plusmn,15%)	Inductance min at 5 A (H)	Pri	Sec1	Sec2	Leakage Inductance max (H) 2	Pri : Sec1 : Sec2	Isolation Voltage (Vrms) 3
Q4337-BL	22.0	19.8	0.03	0.32	0.32	2.0	1 : 2.5 : 2.5	500
