N5182B ВЧ-генератор Agilent

Features:

• 9 kHz to 3 or 6 GHz Depending on Options
• +24 dBm specified power to 3 GHz with electronic attenuator
• 146 dBc phase noise at 1 GHz and 20 kHz offset
• ≤-73 dBc ACP W-CDMA 64 DPCH and &lt,0.4% EVM 160 MHz 802.11 AC

Modulation and sweep

• AM, FM, ØM, pulse, and narrow pulse
• Pulse train generator
• 10 MHz multifunction generator and LF out
• Digital step and list sweep modes

Automation and communication interface

• 1000BaseT LAN, LXI, USB 2.0, and GPIB
• SCPI, IVI-COM, MATLAB drivers
• Backward compatible with ESG, MXG, PSG, and 8648x signal generators
• Agilent USB power sensor compatible with embedded display and SCPI control

Generate the signals you need with outstanding hardware performance

• Test radar receiver sensitivity or characterize ADC or mixer signal-to-noise ratio, with unmatched phase noise and spurious performance
• Drive receiver front-ends for out-of-band rejection with industry-leading output power
• Simulate multi-channel composite analog modulation with integrated multifunction generator
• Create variable RADAR PRI and pulse width with integrated pulse train generator

Maximize resources with low cost of ownership

• Increase uptime with high mean time between failures (MTBF) based on first- generation MXG track record
• Minimize downtime and expenses with self-maintenance strategy and low-cost repairs

Whether you”re pushing for more dynamic range or an optimized receiver rejection, the Agilent N5182B MXG delivers what you need: phase noise, non-harmonics, output power, and more. Take your devices and designs to the limit with the MXG.
