MSS4020-393

General specification Core Material: Ferrite Weight: 81.0 – 87.8 mg Packaging: 2000/13 reel, Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 2.2 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

450,00 ₽

Артикул: MSS4020-393MLD Категорий: Ferrite Drum, MSS4020-393, Power, Products, Shielded Inductors, МСС МОС, МСС4020

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	DCR max (Ω) 3	SRF typ (MHz) 4	Isat (A) 5			Irms (A) 6
Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	DCR max (Ω) 3	SRF typ (MHz) 4	10% drop	20% drop	30% drop	20C rise	40C rise
MSS4020-393ML_	39	0.82	28.5	0.28	0.32	0.36	0.44	0.58

Каталог

AF1107-1xxx | Economy variable frequency drive, single-phase, single-axis module, 0.75 kWNew
