MSS1260-183

General specification Core Material: Ferrite Weight: 2.8 – 3.3 g Packaging: 500/13 reel, Plastic tape: 24 mm wide, 0.5 mm thick, 16 mm pocket spacing, 6.9 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

450,00 ₽

Артикул: MSS1260-183MLD Категорий: Ferrite Drum, MSS1260-183, Power, Products, Shielded Inductors, МСС МОС, МСС1260

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	DCR (mΩ) 3		SRF typ (MHz) 4	Isat (A) 5			Irms (A) 6
Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	typ	max	SRF typ (MHz) 4	10% drop	20% drop	30% drop	20C rise	40C rise
MSS1260-183ML_	18	30.0	33.0	16.0	4.6	5.2	5.6	2.5	3.3

Каталог

AX1103-3xxx | Economy servo drive, three-phase, single-axis module, 3.4В ANew

AF1115-3xxx | Economy variable frequency drive, three-phase, single-axis module, 1.5В kWNew
