MSS1246H-123

General specification Core Material: Ferrite Weight: 2.24 – 2.49 g Packaging: 800/13 reel, Plastic tape: 24 mm wide, 0.35 mm thick, 16 mm pocket spacing, 5.3 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
