Miniature Surface Mount Transformers

General specification Weight: Q4470-CL, S5394-CL, U6982-CL = 510 — 550 mg, S5499-DL,T6437-DL,T6650-DL = 0.98 — 1.1 g Packaging: C Size: 1000 per 13 reel Plastic tape: 16 mm wide, 0.34 mm thick, 12 mm pocket spacing, 5.33 mm pocket depth D Size: 500 per 13 reel Plastic tape: 24 mm wide, 0.36 mm thick, 16 mm pocket spacing, 6.13 mm pocket depth Soldering/Washing Resistance to soldering heat: Three reflows at &gt,217C for 90 seconds (+260C &plusmn,5C for 20 40 seconds), allowing parts to cool to room temperature between. Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
