M2022-ALP

General specification Core Material: Ferrite Weight: M2022-AL 155 mg, M2022-ALPL 85.5 mg, M2022-ASL 319 mg Packaging: 600 per 7 reel, 2200 per 13 reel Plastic tape: 12 mm wide, 8 mm pocket spacing M2022-AL: 0.3 mm thick, 3.7 mm pocket depth M2022-ALP: 0.3 mm thick, 2.25 mm pocket depth M2022-AS: 0.25 mm thick, 3.94 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
