LPZ5015-475

General specification Core Material: Ferrite Weight: 22 – 25 mg Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: LPZ3008 OD: 3 mm, ID: &lt,1.5 mm LPZ4018 OD: 4 mm, ID: &lt,2 mm LPZ3010 OD: 3 mm, ID: &lt,1.5 mm LPZ4414 OD: 4.5 mm, ID: &lt,2 mm LPZ3015 OD: 3 mm, ID: &lt,1.5 mm LPZ5010 OD: 5 mm, ID: &lt,2.5 mm LPZ3314 OD: 3.3 mm, ID: &lt,1.65 mm LPZ5015 OD: 5 mm, ID: &lt,2.5 mm LPZ4012 OD: 4 mm, ID: &lt,2 mm PCB Washing: Tested with pure water or alcohol only. More info
