LPS8045B-334

General specification Core Material: Ferrite Weight: 0.88 – 1.1 g Packaging: 250/7 reel, 1000/13 reel, Plastic tape: 16 mm wide, 0.28 mm thick, 12 mm pocket spacing, 4.83 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 8mm, ID:4 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
