LPS3314-333

General specification Core Material: Ferrite Weight: 37.3 – 57.3 mg Packaging: 1000/7 reel, 3500/13 reel Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 1.52 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 3.3 mm, ID: &lt, 1.65 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
