LPS3030-103

General specification Core Material: Ferrite Weight: 80 – 90 mg Packaging: 600/7 reel, 2000/13 reel, Plastic tape: 12 mm wide, 0.30 mm thick, 8 mm pocket spacing, 3.3 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycle Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 3 mm, ID: &le, 1.5 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
