LPD6235-682

General specification Core Material: Ferrite Weight: 420 – 480 mg Packaging: 350/7 reel, 1500/13 reel Plastic tape: 16 mm wide, 0.3 mm thick, 12 mm pocket spacing, 3.68 mm pocket depth Winding to Winding Isolation: 100 Vrms, one minute Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 6.2 mm, ID: &le, 3.1 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
