LPD5030V-333
General specification Core Material: Ferrite Weight: 210 – 225 mg Packaging: 750/7 reel, 2500/13 reel Plastic tape: 12 mm wide, 0.32 mm thick, 8 mm pocket spacing, 3.1 mm pocket depth. Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Three reflows at >,217C for 90 seconds (+260C ±,5C for 20 40 seconds), allowing parts to cool to room temperature between. Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 5 mm, ID: &le, 2.5 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
225,00 ₽
Specifications
Electrical specifications at 25C.
For Flyback Applications
| Part number 1 (Hover for schematics) | Inductance (H) 2 (Tolerance: ±,20%) | DCR max (Ω) 3 | Isolation Voltage (V) 4 | Leakage Inductance (H) 6 | Turns Ratio |
|---|---|---|---|---|---|
| LPD5030V-333MR_ | 33 | 0.895 | 1000 | 0.20 | 1 : 1 |
For SEPIC Applications
| Part number 1 (Hover for schematics) | Inductance (H) 2 (Tolerance: ±,20%) | DCR max (Ω) 3 | SRF typ (MHz) 5 | Coupling coefficient | Leakage Inductance (H) 6 | Isat (A) 7 | Irms (A) | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 10% drop | 20% drop | 30% drop | both windings 8 | one winding 9 | ||||||
| LPD5030V-333MR_ | 33 | 0.895 | 19.2 | 0.98 | 0.20 | 0.49 | 0.59 | 0.67 | 0.43 | 0.61 |
