LPD5010-102

General specification Core Material: Ferrite Weight: 60 – 70 mg Winding to Winding Isolation: 100 Vrms, one minute Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 5 mm, ID: &le, 2.5 mm PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

225,00 ₽

Артикул: LPD5010-102MRC Категорий: Data Line Common Mode Choke, EMI, LPD5010, Products, ЛПД5010-102

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Lines	Common mode peak impedance (kΩ)	Cutoff frequency (MHz) 2	Inductance min (H) 3	Irms (A) 4	DCR max (Ω) 5	Isolation Voltage (Vrms) 6
Part number 1	Lines	Common mode peak impedance (kΩ)	Cutoff frequency (MHz) 2	Inductance min (H) 3	Irms (A) 4	DCR max (Ω) 5	Isolation Voltage (Vrms) 6
LPD5010-102MR_	2	1.43 @ 160 MHz	530	0.80	1.50	0.10	100
