Keysight DP0034A – High Voltage Differential Probe (70 MHz, 7000V)

Description

Keysight DP0034A

• Compatible with Keysight oscilloscopes with 1 MΩ AutoProbe interfaces
• 70 MHz bandwidth, ±7,000 V differential (DC + AC peak)
• attenuation ratios: 2,500 / 250:1, auto-switchable
• differential input impedance: 50 MΩ || 2pF
• DC common mode rejection &gt,80 dB

High Voltage Differential Probe (70 MHz, 7000V)

The DP003xA series of high-voltage, differential active probes provides superior general-purpose differential signal measurements required for high-speed power measurements such as measuring characteristics of switching power devices, DC-DC converters, class D amplifiers, automotive bus measurements, and high-speed digital system designs. As designs become more complex and the need for floating measurements grows, these differential probes enable floating measurements between any two points on a board and can also function as single-ended probes with one terminal connected to ground.

Several Versions Available

The DP003xA series of probes is available in several models with various bandwidths and differential voltages. The DP0030A has a BNC+USB oscilloscope interface. Please see the table below for a comparison.

ModelBandwidthMax Differential (DC+AC)Attenuation (high/low)InterfaceDP0030A100 MHz+/- 750V250/25:1BNC + USBDP0031A200 MHz+/- 750V250/25:1AutoProbe1DP0032A200 MHz+/- 1500V500/50:1AutoProbe1DP0033A200 MHz+/- 3000V1000/100:1AutoProbe1DP0034A70 MHz+/- 7000V2500/250:1AutoProbe1
