Технические характеристики

Type number C15550-20UP
Imaging device qCMOS image sensor
Effective no. of pixels 4096 (H) × 2304 (V)
Cell size 4.6 μm (H) × 4.6 μm (V)
Effective area 18.841 mm (H) × 10.598 mm (V)
Full well capacity 7000 electrons (typ.)
Readout speed Standard scan*1: 120 frames/s (At full resolution, CoaXPress)
Standard scan*1: 17.6 frames/s (At full resolution, USB)
Ultra quiet scan: 5 frames/s (At full resolution, CoaXPress, USB)
Readout noise Standard scan: 0.43 electrons rms (typ.)
Ultra quiet scan: 0.27 electrons rms (typ.)
Exposure time Standard scan*1: 7.2 μs to 1800 s
Ultra quiet scan:199.9 ms *2 to 1800 s (internal, edge, level, start)
Ultra quiet scan:200.2 ms *2 to 1800 s (sync readout)
Ultra quiet scan:172.8 μs to 1800 s (global reset edge, global reset level)
Cooling temperature Forced-air cooled (Ambient temperature: +25 °C) : -20 ℃
Water cooled (Water temperature: +25 °C)*3 : -20 ℃
Water cooled (Max cooling, The water temperature is +20 ℃ and the ambient temperature is +20 ℃) *3: -35 ℃ (typ.)
Dark current Forced-air cooled (Ambient temperature: +25 °C) : 0.016 electrons/pixels/s (typ.)
Water cooled (Water temperature: +25 °C) : 0.016 electrons/pixels/s (typ.)
Water cooled (Max cooling, The water temperature is +20 ℃ and the ambient temperature is +20 ℃) : 0.006 electrons/pixels/s (typ.)
Dynamic range 25 900:1 (typ.)*4
External trigger mode Edge / Global reset edge / Level / Global reset level / Sync readout / Start
External trigger signal routing SMA
Trigger delay function 0 s to 10 s in 1 μs steps
Trigger output Global exposure timing output / Any-row exposure timing output / Trigger ready output / 3 programmable timing outputs / High output / Low output
External signal output routing SMA
Image processing functions Defect pixel correction (ON or OFF, hot pixel correction 3 steps)
Emulation mode Available (ORCA-Fusion)
Interface USB 3.1 Gen 1, CoaXPress (Quad CXP-6)
A/D converter 16 bit, 12 bit, 8 bit
Lens mount C-mount*5
Power supply AC100 V to AC240 V, 50 Hz/60 Hz
Power consumption Approx. 155 VA
Ambient operating temperature 0 °C to +40 °C
Ambient storage temperature －10 °C to +50 °C
Ambient operating humidity 30 % to 80 % (With no condensation)
Ambient storage humidity 90 % Max. (With no condensation)
