KA5038-BL

General specification Core Material: Ferrite Weight: 60.2 g

3600,00 ₽

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 2.8 A (H)	DCR max (Ω) 3			Leakage Inductance max (H) 4	Turns Ratio 5	Isolation Voltage (Vrms) 6
Part number (Hover for schematics)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 2.8 A (H)	Pri	Sec	Aux	Leakage Inductance max (H) 4	Pri : Sec : Aux	Isolation Voltage (Vrms) 6
KA5038-BL	560	480	0.198	0.007	0.236	5.6	1 : 0.188 : 0.156	3000
