JA4220

General specification Core Material: Ferrite Weight: 90 mg max Packaging: 750/7 reel, 3000/13 reel, Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 2.9 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

900,00 ₽

Артикул: JA4220-ALC Категории: JA4220, Products, Transformers, Wideband RF Transformers

Описание

Specifications

Electrical specifications at 25C. Measurements are referenced to 50 Ohms.

Part number 1 (Hover for schematics)	L min per winding (H) 2		DCR max (mΩ) 3		Imp. ratio pri:sec	Current rating (mA)	Insertion loss (db)	Bandwidth (MHz)
Part number 1 (Hover for schematics)	Pri	Sec	Pri	Sec	Imp. ratio pri:sec	Current rating (mA)	Insertion loss (db)	Bandwidth (MHz)
JA4220-AL_	15	15	120	120	1 : 1	250	0.2	0.1 3500
