IFLY0012L

General specification Core Material: Ferrite Weight: 5.2 g Packaging: 200/13 reel Plastic tape: 44 mm wide, 0.4 mm thick, 28 mm pocket spacing, 9.6 mm pocket depth Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at PCB Washing: Only pure water or alcohol recommended

675,00 ₽

Артикул: IFLY0012LD Категорий: IFLY0012, IFLY0012L, Power Converter Transformers, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 6.5 A (H)	DCR max (Ω)				Leakage Inductance max (H)	Turns Ratio	Isolation Voltage (Vrms) 3
Part number 1 (Hover for schematics)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 6.5 A (H)	Pri	Sec1	Sec2	Sec3	Leakage Inductance max (H)	Pri : Sec1 : Sec2 : Sec3	Isolation Voltage (Vrms) 3
IFLY0012L_	6.0	4.8	0.021	0.690	0.690	0.690	0.3	1 : 3 : 3 : 3	500
