Технические характеристики

Photocathode Area Shape Round
Photocathode Area Size Dia.8 mm
Wavelength (Short) 230 nm
Wavelength (Long) 700 nm
Wavelength (Peak) 400 nm
Dimension (W x H x D) 30.0 mm x 22.0 mm x 54.0 mm
Input Voltage +4.75 V to +5.25 V
Max. Input Voltage 6 V
Max. Input Current 40 mA
Count Sensitivity at 300 nm Typ. 3.9 x 105 s-1・pW-1
Count Sensitivity at 400 nm Typ. 6.1 x 105 s-1・pW-1
Count Sensitivity at 500 nm Typ. 4.6 x 105 s-1・pW-1
Count Sensitivity at 600 nm Typ. 1.3 x 105 s-1・pW-1
Count Sensitivity at 700 nm Typ. 9.1 x 103 s-1・pW-1
Count Linearity 5.0 x 106 s-1
Dark Count Typ. 50 s-1
Dark Count Max. 100 s-1
Pulse-pair Resolution 20 ns
Output Pulse Width 10 ns
Output Pulse Height Min. 2 V
Output Pulse Height Typ. 2.2 V
Recommended Load Resistance 50 Ω
Signal Output Logic Positive logic
Operating Ambient Temperature +5 ℃ to +40 ℃
Storage Temperature -20 ℃ to +50 ℃
Weight 61 g
