FL2810-1L

General specification Weight: 3.6 – 6.1 g Packaging: Package 1: 400/13 reel 44 mm tape width Package 4: 750/13 reel 44 mm tape width Package 5: 1000/13 reel 56 mm tape width For packaging data see Tape and Reel Specifications section. Soldering/Washing Resistance to soldering heat: Three reflows at &gt,217C for 90 seconds (+260C &plusmn,5C for 20 40 seconds), allowing parts to cool to room temperature between. Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

1125,00 ₽

Артикул: FL2810-1LD Категорий: CCFL Transformers, FL, FL2810-1L, Power Transformers, Products, Трансформеры

Описание

Specifications

Electrical specifications at 25C.

Package 4

Part number 1	Schematic	Turns Ratio	Power (W)	Inductance typ (H) 2	Imax sec (A)	Vrms (V) 3		Vinst max (V) 4		DCR max (Ω) 5		Isolation Voltage (Vrms) 6
Part number 1	Schematic	Pri : Sec	Power (W)	Inductance typ (H) 2	Imax sec (A)	Pri	Sec	Pri	Sec	Pri	Sec	Isolation Voltage (Vrms) 6
FL2810-1L_	C	1 : 100	4.5	35	0.007	15	1500	16.5	1650	0.22	500	500
