Elma Bustronic 116FFE6018-012XR Rev. A Backplane

Unit is a VMetro MDR-220 MIDAS data recorder VME. Specifications: -Pre-programmed, self-contained VMEbus module with two PMC sites -PMC modules installed into sites onto the MDR boards –DPIO-xI – data input interface to convert 32-bit parallel FPDP to PCI –DPIO-xO – data output interface to convert PCI to 32-bit parallel FPDP –VMFC-2100 – PMC Fiber Channel Adapter –Ethernet host interface supporting TCP/IP over 10/100 Mbits/s -Mass storage system based on 3rd-party Fibre Channel disk arrays. –RAID – Redundant Array of Inexpensive Disks –JBOD – Just a Bunch of Disks -PCI Module plugged directly into Host Computer. –VMFC-2100P – (or VMFC-2200P) Fiber Channel Disk Interface Adapter.

Это модуль базовой платы Pentek 4200A 4201A MIX VME.
