DA2099-AL

General specification Core Material: Ferrite Weight: 1.35 g Packaging: 500/13 reel, Plastic tape: 24 mm wide, 0.36 mm thick, 20 mm pocket spacing, 6.13 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. More info.

450,00 ₽

Артикул: DA2099-ALD Категорий: DA2099, DA2099-AL, Gate Drive, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Inductance at 0A (mH) 2 (Tolerance: &plusmn,20%)	DCR max (Ω) 3		Leakage Inductance max (H) 4	Turns Ratio	Capacitance max (pF)	Volt-time product (V-s) 5	Isolation Voltage (Vrms) 6
Part number 1 (Hover for schematics)	Inductance at 0A (mH) 2 (Tolerance: &plusmn,20%)	Pri	Sec	Leakage Inductance max (H) 4	Pri : Sec	Capacitance max (pF)	Volt-time product (V-s) 5	Isolation Voltage (Vrms) 6
DA2099-AL_	3.79	2.30	2.85	13	1 : 1	13	221	1500
