CST1-100L

General specification Core Material: Ferrite Weight: 0.4 g Packaging: 250/7reel,1000/13 reel, Plastic tape: 16 mm wide, 0.35 mm thick, 12 mm pocket spacing, 5.6 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Three reflows at &gt,217C for 90 seconds (+260C &plusmn,5C for 20 40 seconds), allowing parts to cool to room temperature between. Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

450,00 ₽

Артикул: CST1-100LC Категорий: CST1-100L, CST1-CST2, Current Sensing, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Inductance min (H) 2	DCR max (Ω) 3		Turns Ratio	Volt-time product (V-s) 4	Frequency (kHz) 5	Current (A) 6	Terminating resistance R_T () 7	Isolation Voltage (Vrms) 8	Color dot
Part number 1 (Hover for schematics)	Inductance min (H) 2	Pri	Sec	Pri : Sec	Volt-time product (V-s) 4	Frequency (kHz) 5	Current (A) 6	Terminating resistance R_T () 7	Isolation Voltage (Vrms) 8	Color dot
CST1-100L_	2000	0.0007	5.5	1 : 100	54	9 &gt,1000	20.0	5.0	500	Gray
