Comet T2314 – Barometric Pressure Transmitter, RS232 Output

Description

Comet T2314

• Barometric pressure transmitter for outdoor and indoor use
• Display reading and pressure output is user selectable
• Measured pressure values are converted to RS232 serial output
• Works with ModBus RTU communication protocol
• Two Line LCD

Barometric Pressure Transmitter, RS232 Output

Barometric pressure transmitter for outdoor and indoor use. Display reading and pressure output is user selectable in these units: hPa, kPa, mbar, mmHg, inHg, inH2O, PSI, oz/in2. Measured pressure values are converted to RS232 serial output.

Serial output RS232 – transmitter works with ModBus RTU communication protocol or with Advantech ADAM compatible protocol. Protocol is user selectable in special configuration mode by means of the PC. Serial link enables to read actual readings and modify transmitter configuration. Instrument works always in slave mode, i.e. responds only to master device query. Transmitters have the address space available from 1 to 255. Communication speed is 110 to 115200Bd.

Applications

• Building HVAC management
• Building HVAC automation
• Warehouses
• Glasshouses
• Manufacturers
• Museums, archives, galleries
• Air-conditioned rooms
• Weather stations

Software

• Comet Database
• Complex solution for data acquisition and analysis. Easy to use and high flexible Database software for Comet Transmitters and Regulators.
• T-Sensor Software
• Free configuration utility for Comet Transmitters and Regulators.
• Sensor Reader Software
• Basic data acquisition utility for Comet Transmitters and Regulators. Software is free for download.
