Comet T0418 – Interior Temperature Transmitter with RS485 Output

Description

Comet T0418

• Temperature sensor with RS485 output
• Measured temperature values are converted to RS485 serial output
• For exacting interiors in building energy management and HVAC systems
• Are designed for easy installation on ordinary KU68 wiring boxes for household switches and sockets
• Serial link enables to read actual readings and modify transmitter configuration

Interior Temperature Transmitter with RS485 Output

Programmable transmitters with RS232 or RS485 serial interface are designed to measure temperature, relative humidity, and barometric pressure in exacting interiors in building energy management and HVAC systems.

Digital conception with microprocessor allows determining the other computed humidity values, like dew point temperature, absolute humidity, specific humidity, mixing ratio, and specific enthalpy. Measured and calculated values are displayed on a two-line LCD display. Devices support Modbus RTU protocol, protocol compatible with standard Advantech-ADAM, ARION protocol, and communication with HWg-Poseidon devices. For a set of all parameters, you can use TSensor software.

Measuring of Temperature, Humidity, and CO2 Level at:

• Building HVAC Management
• Building HVAC Automation
• Warehouse
• Meeting rooms, hospitals, cinemas, theatres
• Air Condition Rooms

Measured temperature values are converted to RS485 serial output For exacting interiors in building energy management and HVAC systems Are designed for easy installation on ordinary KU68 wiring boxes for household switches and sockets Serial link enables to read actual readings and modify transmitter configuration Instrument works always in slave mode, i.e. responds only to master device query.

Software

• Comet Database
• Complex solution for data acquisition and analyzing. Easy to use and high flexible Database software for Comet Transmitters and Regulators.
• Sensor RS485/232 Utility
• Allows communication of sensors with RS485/RS232 output and sending data to Comet Database.
• T-Sensor Software
• Free configuration utility for Comet Transmitters and Regulators.
• SensorReader Software
• Basic data acquisition utility for Comet Transmitters and Regulators. Software is free for download.
