CMT3-32-1

General specification Core Material: Iron Weight: CMT1: 13.3 – 25.5 g, CMT2: 20.7 – 41.7 g, CMT3: 42.5 – 77.2 g, CMT4: 115 – 117 g Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

2025,00 ₽

Артикул: CMT3-32-1L Категорий: CMT, CMT3-32-1, EMI, Power Line Common Mode Choke, Products

Описание

Specifications

Electrical specifications at 25C.

CMT-3 Series

Part number	Lines	Common mode peak impedance (kΩ)	Inductance min (mH) 1	Leakage Inductance max (H) 2	Irms (A)	DCR max (Ω) 3	Isolation Voltage (Vrms) 4
Part number	Lines	Common mode peak impedance (kΩ)	Inductance min (mH) 1	Leakage Inductance max (H) 2	Irms (A)	DCR max (Ω) 3	Isolation Voltage (Vrms) 4
CMT3-32-1L	2	41.91 @ 0.10 MHz	32.0	485	1.0	0.65	1250
