B0863-BL

General specification Core Material: Ferrite Weight: 5.6 g Packaging: 200 per 13 reel Plastic tape: 44 mm wide, 0.35 mm thick, 28 mm pocket spacing, 9.6 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. More info.

900,00 ₽

Артикул: B0863-BLD Категорий: B0863, B0863-BL, Power Converter Transformers, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 2 (Hover for schematics)	Inductance min (H) 3	DCR max (Ω) 4					Leakage Inductance max (H) 5	Turns Ratio 6	Isolation Voltage (Vrms) 7
Part number 2 (Hover for schematics)	Inductance min (H) 3	Pri	Sec	Drive	Bias	Reset	Leakage Inductance max (H) 5	Pri : Sec : Drive : Bias : Reset	Isolation Voltage (Vrms) 7
B0863-BL_	165.0	0.061	0.008	0.020	1.290	1.100	0.75	1 : 0.24 : 0.24 : 1.3 : 1	1500
