B0853-AL

General specification Core Material: Ferrite Weight: 11.6 g Packaging: 200/13 reel 44 mm tape width

2250,00 ₽

Артикул: B0853-ALD Категорий: B0853, B0853-AL, Planar Transformers, Products, Transformers

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Inductance min (H) 2	DCR max (mΩ) 3			Leakage Inductance max (H) 4	Turns Ratio 5	Isolation Voltage (Vrms) 6
Part number 1 (Hover for schematics)	Inductance min (H) 2	Pri	Sec	Aux	Leakage Inductance max (H) 4	Pri : Sec : Aux	Isolation Voltage (Vrms) 6
B0853-AL_	46.8	10.4	4.0	160.0	0.10	1 : 0.8 : 0.8	1500
