Autonics PRDWT08-4DO-IV – Cylindrical Inductive Proximity Sensor

Description Autonics PRDWT08-4DO-IV – Cylindrical Inductive Proximity Sensor

• Wire type and power: DC 2-wire type 12-24VDC
• Sensing side diameter: M8
• Sensing distance: 4mm
• Installation: Non-shield(non-flush)
• Standard sensing target: 12×12×1mm(iron)
• Cable Standard/material: Oil resistant cable(IEC standard)

The Autonics PRDWT08-4DO-IV PRDW series inductive proximity sensor features a long sensing distance and excellent noise immunity with a specialized sensor IC developed by Autonics. The cable connector type sensors offer easier maintenance and wiring work.

Available in M8 sensing side diameter and 4mm sensing distance and 12×12×1mm(iron) standard sensing target, the PRDWT08-4DO-IV can be used in diverse applications requiring non-contact detection of metallic objects. The sensors also feature strain relief cables for improved flexural strength and durability. The PRDWT08-4DO-IV is available in DC 2-wire and Oil resistant (IEC standard) cable.

Long Sensing Distance

The PRDW series sensors feature longer sensing distance (1.5 to 2x) compared to Autonics PRW series standard inductive sensors.

Oil-Resistant (PVC) Cable

The robust oil-resistant cable allows the sensors to be installed in environments with hydraulic fluids or cutting fluids.

IP67 Protection Structure

The IP67 protection structure allows stable and error-free operation even in wet or dusty environments.
