AGM2222-103

General specification Core Material: Powdered Iron Weight: 46 – 51 g Packaging: 42 parts per tray Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

2700,00 ₽

Артикул: AGM2222-103ME Категорий: AGM2222, AGM2222-103, AGP VER, High current flat wire, Power, Products, Shielded Inductors

Описание

Specifications

Electrical specifications at 25C.

Part number	Inductance (H) 1 (Tolerance: &plusmn,20%)	DCR (mΩ) 2		SRF typ (MHz) 3	Isat (A) 4			Irms (A) 5
Part number	Inductance (H) 1 (Tolerance: &plusmn,20%)	typ	max	SRF typ (MHz) 3	10% drop	20% drop	30% drop	20C rise	40C rise
AGM2222-103ME	10.0	2.08	2.50	23.0	15.0	26.0	37.0	21.0	30.0

Каталог

AF1107-1xxx | Economy variable frequency drive, single-phase, single-axis module, 0.75 kWNew
