86105B 15 GHz optical / 20 GHz electrical module

• Wavelength range: 1000-1600 nm
• Characteristic rms noise: 5 uW (10 GHz BW), 10 uW (15 GHz BW)
• Maximum average input power: 2 mW
• Reference receiver capability: see options for supported data rates

20 GHz electrical channel with 3.5 mm male input

• Characteristic rms noise: 0.25 mV (12.4 GHz BW), 0.5 mV (20 GHz BW)
• Maximum input signal: +/- 2 Vdc

Compatibility

• 86100A/B Infiniium DCA Mainframes
• 86100C Infiniium DCA-J Mainframe
• 86100D Infiniium DCA-X Mainframe



The Keysight 86105B lets you perform transmitter compliance tests of multiple technologies and line rates with a single module. It is now possible to characterize optical transmission performance of SONET, Ethernet, and Fibre Channel technologies, from 155 Mb/s through 10 Gb/s. In addition, new Infiniium DCA firmware now supports mask testing for emerging standards such as optical InfiniBand and electrical XAUI signaling.
