2929SQ-391

General specification Temperature coefficient of inductance: +5 to +70 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Three reflows at &gt,217C for 90 seconds (+260C &plusmn,5C for 20 40 seconds), allowing parts to cool to room temperature between. Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: 1515SQ: OD: 0.170 inch, ID: 0.059 inch 2222SQ, 47 200 nH: 3.5 mm 7 mm (rubber). This nozzle is available here. 2222SQ, 270 300 nH: 4.0 mm 12 mm (rubber). This nozzle is available here. 2929SQ: 4.0 mm 12 mm (rubber). This nozzle is available here. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
