1812SMS-47N

General specification Weight: 0.10– 0.16 g Packaging: 500/7 reel, 2000/13 reel Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 4.33 mm pocket depth Temperature coefficient of inductance: +5 to +70 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. Recommended Pick & Place Nozzle: OD: 0.110 inch, ID: 0.091 inch PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info
