164-04A06L

General specification Core Material: Aluminum, 0.187″ (4.75 mm) long Weight: 164 series unshielded: 0.16 – 0.31 g, with shield can: 0.45 – 0.60 g, 165 series unshielded: 0.15 – 0.25 g, with shield can: 0.43 – 0.54 g Packaging: 50 parts per tube Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Wave solder only. Recommended maximum board surface temperature of 168C (334F) for no more than three seconds. Pre-heating is recommended to minimize time over the solder nozzle. Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
