146-02J08L

General specification Core Material: Carbonyl J, 1/4′ long Weight: 146 series unshielded: 0.44 – 0.7g, with shield can: 0.91 – 1.12g, 150 series unshielded: 0.45 – 0.61g, with shield can: 0.88 – 1.08g Packaging: Unshielded: 85 per tube With shield can: 75 per tube Soldering/Washing Resistance to soldering heat: Wave solder only. Recommended maximum board surface temperature of 168C (334F) for no more than three seconds. Pre-heating is recommended to minimize time over the solder nozzle. Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
