1210POC-103

General specification Core Material: Ferrite Weight: 115 – 125 mg Packaging: 750/7 reel, 3000/13 reel, Plastic tape: 12 mm wide, 0.25 mm thick, 8 mm pocket spacing, 2.72 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

225,00 ₽

Артикул: 1210POC-103MRC Категорий: 1210POC, 1210POC-103, Conical Broadband, Products, РФ

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	DCR (Ω) 3		SRF typ (MHz) 4	Isat (mA) 5					Irms typ (A)
Part number 1	Inductance (H) 2 (Tolerance: &plusmn,20%)	typ	max	SRF typ (MHz) 4	25C	85C	105C	125C	140C	at 25C 6	at 85C 7	at 125C 8
1210POC-103MR_	10	0.34	0.34	95	1100	850	760	660	560	1.1	1.0	0.57
