0603USB-951

General specification Core Material: Ferrite Weight: 4.9 – 5.2 mg Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

0,00 ₽

Артикул: 0603USB-951MLC Категорий: 0603USB, 0603USB-951, Data Line Common Mode Choke, EMI, Products

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Lines	Common mode peak impedance (kΩ)	Cutoff frequency (GHz) 2	Common mode attenuation typ (dB)			Inductance min (nH) 3	Irms (mA) 4	DCR max (Ω) 5	Isolation Voltage (Vrms) 6
Part number 1	Lines	Common mode peak impedance (kΩ)	Cutoff frequency (GHz) 2	10 MHz	500 MHz	1 GHz	Inductance min (nH) 3	Irms (mA) 4	DCR max (Ω) 5	Isolation Voltage (Vrms) 6
0603USB-951ML_	2	0.30 @ 2.6 GHz	2.8	4.62	9.75	16.06	63	500	0.142	250
