0603HP-11N

General specification Core Material: Ceramic Weight: 2.0 – 3.2 mg Packaging: 2000/7 reel, 10000/13 reel. Paper tape: 8 mm wide, 1 mm thick, 4 mm pocket spacing Temperature coefficient of inductance: +25 to +125 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info
