0603AF-15N

General specification Core Material: Ferrite Weight: 4.3 – 5.7 mg Packaging: 2000/7 reel, 10000/13 reel. Paper tape: 8 mm wide, 1.0 mm thick, 4 mm pocket spacing Temperature coefficient of inductance: +50 to +300 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

225,00 ₽

Артикул: 0603AF-15NXJRW Категорий: 0603AF, 0603АФ-15Н, Ferrite Core Chip Inductors, Products, РФ

Описание

Specifications

Electrical specifications at 25C.

Part number 1	Inductance (nH) 2 (Tolerance: &plusmn,5%)	Impedance typ (Ω)		Q typ @ 7.9 MHz	SRF typ (GHz) 3	DCR max (Ω) 4	Irms (A) 5	Color code 6
Part number 1	Inductance (nH) 2 (Tolerance: &plusmn,5%)	100 MHz	500 MHz	Q typ @ 7.9 MHz	SRF typ (GHz) 3	DCR max (Ω) 4	Irms (A) 5	Color code 6
0603AF-15NXJR_	15	10.0	42.0	13	3.5	0.023	2.1	Yellow
