0603AF-152

General specification Core Material: Ferrite Weight: 4.3 – 5.7 mg Packaging: 2000/7reel, 10000/13 reel Plastic tape: 8 mm wide, 1 mm thick, 4 mm pocket spacing Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
