0402DF-121

General specification Core Material: Ferrite Weight: 0.9 – 1.1 mg Packaging: 2000 or 10000 per 7 reel. Paper tape: 8 mm wide, 0.68 mm thick, 2 mm pocket spacing Temperature coefficient of inductance: +25 to +150 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info
