Phase II+ UTG-2900 Ultrasonic Thickness Gauge with Thru Coating

Description Phase II+ UTG-2900 Ultrasonic Thickness Gauge with Thru Coating

• Designed to measure the thickness of metallic and non-metallic materials
• Packed with features typically found on high end models only
• Backlit 4-digit LCD Display
• Display readings in either inch or millimeter

Our new State of the art, digital ultrasonic thickness gauger is packed with features typically found on high end models only. This multi-functional ultrasonic thickness gauge offers everything from basic measurement, Thru Coating capabilities, Scanning Capabilities, Adjustable Sound Velocity, extended memory and USB output capabilities. This dynamic ultrasonic thickness gauge is designed to measure the thickness of metallic and non-metallic materials such as steel, aluminum, titanium, plastics, ceramics, glass and any other good ultrasonic wave conductor as long as it has parallel top and bottom surfaces. The UTG-2900 ultrasonic thickness gauge will accurately display readings in either inch or millimeter after a simple calibration to a known thickness or sound velocity.

The highly innovative gauge design features an intuitive interface that makes setup and operation easy. Simply calibrate the gauge to a known thickness or sound velocity and begin taking measurements. Unit accurately displays measurement results in either inch or millimeter.

Phase II Ultrasonic Thickness Gauge Comparison Model UTG-1500 UTG-2800 UTG-2900 UTG-4000 UTG-2650 Probe Type 5 MHz Dual Element 5 MHz Dual Element 5 MHz Dual Element 5 MHz Dual Element Single Delay Line Mode Single Echo Single Echo Single Echo
& Multiple Echo
Single Echo
& Multiple Echo
Single Echo
& Multiple Echo
Measurement Range 0.05” to 8.0” 0.04′ to 12.000′ Single Echo: 0.03′ to 23.000′
Mult. Echo: 0.118” – 3.50” Steel (up to 35mil coating)
Single Echo: 0.02′ to 20.000′
Mult. Echo: 0.118” – 3.50” Steel (up to 35mil coating)
Single Echo: 0.059′ to .787′
Mult. Echo: 0.012” – 0.394”
Thru-Paint Capability No No Yes Yes No Adjustable Sound Velocity Yes Yes Yes Yes Yes A-Scan/B-Scan No No No Yes No Memory/Data Output No Yes: 20 groups (up to 99readings/group) / USB Yes: 20 groups (up to 99readings/group) / USB Yes: 20 groups (up to 99readings/group) / USB Memory: 500 values / No Output Measurement Rate – Normal 3 readings/sec 4 readings/sec 4 readings/sec 4 readings/sec 4 readings/sec Measurement Rate – Scan N/A 10 Readings/sec 16 Readings/sec 16 Readings/sec N/A Resolution 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.0001′ Selectable Accuracy .5%+.2mm .5% +0.001′ .5%+0.001′ 0.001”(up to 0.984”)
0.007”(up to 3.03”)
0.019”( 4” and above)

0.0002′ (below 3mm)
0.002′ (if below 20mm)
Gage Dimensions 161x69x32mm 150x74x32mm 150x74x32mm 153x76x37mm 149x73x42mm Weight (without batteries) 10.5oz. 8.6 oz. 8.6 oz. 9.9 oz. 5.6 oz. Warranty 5 Years 5 Years 5 Years 5 Years 5 Years List Price $595.00 $795.00 $995.00 $2,895.00 $1,995.00
